SNMP Polling

In the previous chapter, we explored monitoring strategies that relied on both active and passive Zabbix agents. This chapter introduces an alternative approach monitoring via SNMP (Simple Network Management Protocol) which does not require the installation of a Zabbix agent on the monitored device. This method is especially useful in environments where agent based monitoring is impractical, restricted or simply not allowed.

Simple Network Management Protocol (SNMP) is a widely adopted protocol designed for monitoring and managing devices on IP networks. Despite the word "management" in its name, SNMP is predominantly employed for monitoring purposes. Its widespread support across networking hardware and embedded systems has made it a cornerstone of modern network visibility solutions.

Originally developed in the late 1980s, SNMP has undergone several revisions. Early versions, such as SNMPv1 and SNMPv2c, were hampered by significant security limitations. As a result, while SNMP includes functionality for remote device configuration, its use has remained largely to status monitoring rather than active management of devices.

SNMP is especially valuable for monitoring resource constrained or embedded devices that lack the capacity to run a full monitoring agent.

Common examples include:

Printers
Network switches, routers, and firewalls
Uninterruptible Power Supplies (UPSs)
NAS (Network-Attached Storage) appliances
Environmental sensors (e.g., temperature, humidity sensors)

These devices often provide built-in SNMP support, making them accessible for monitoring with minimal configuration. Additionally, SNMP can be employed on standard servers where installing or maintaining a Zabbix agent is either impractical or not permitted. This could be due to administrative policies, software compatibility or security concerns, or simply a desire to reduce system footprint.

Recognizing the ubiquity of SNMP, Zabbix provides native SNMP support. This capability is powered by the open-source Net-SNMP suite, available at http://net-snmp.sourceforge.net. The integration allows Zabbix to retrieve metrics from SNMP-enabled devices using industry-standard mechanisms.

In this chapter, we will cover the following:

An introduction to the Net-SNMP toolkit and its core utilities.
How to integrate MIB (Management Information Base) files into Zabbix, enabling the platform to interpret SNMP data correctly.
The process of SNMP polling within Zabbix, including how to define SNMP-based items and retrieve data from devices.

This chapter serves as the foundation for SNMP-based monitoring in Zabbix. While we begin with the essentials such as polling, MIB usage, and SNMP item configuration this is just the start.

Later in this book, we will build upon this knowledge by exploring Low-Level Discovery (LLD) mechanisms using SNMP. LLD allows Zabbix to automatically detect and create monitoring items for dynamic or repetitive structures, such as network interfaces, power supplies, ...

Net-SNMP

The Simple Network Management Protocol (SNMP) is a widely used protocol for monitoring and managing networked devices. It operates primarily over UDP port 161, though in certain cases, SNMP agents or proxies may also support TCP port 161 for enhanced reliability or integration with specific tools. SNMP allows administrators to query information or trigger actions on remote devices using structured data identified by Object Identifiers (OIDs).

To begin working with SNMP in a lab or testing environment, you may choose between two approaches:

Use an existing SNMP capable device already present in your network infrastructure.
Deploy a lightweight SNMP agent on a general-purpose server, such as your Zabbix server or a dedicated virtual machine.

In this chapter, we will walk through the installation and configuration of a basic SNMP agent on a Rocky or Ubuntu based Zabbix server. However, the same setup can be applied to any compatible Linux system.

Note: If you're using a device already present on your network, ensure:

You have network access to the device (verify routing and firewall settings).
SNMP access is allowed from your Zabbix server’s IP address.
The correct community string is configured, and your IP is included in the SNMP access control rules of the device.

Testing an SNMP Device: Where to Start?

When you're looking to test an SNMP device, it's crucial to understand the available SNMP versions and which ones you should prioritize. Currently, there are three commonly used versions: SNMPv1, SNMPv2c, and SNMPv3.

SNMPv1: This is the oldest version and should generally be avoided unless absolutely necessary. It's quite limited in functionality and has serious security vulnerabilities.
SNMPv2c: Still the most prevalent version today, SNMPv2c offers improvements over v1, especially in data retrieval and performance. It's relatively straightforward to configure and use.
SNMPv3: This version is rapidly gaining popularity and is considered the most secure and advanced option. It provides encryption, authentication, and user management, which are essential for secure networks.

Your First Test Attempt: SNMPv2c and the 'public' Community String

To begin your testing, we recommend trying to connect to your device using SNMPv2c and the standard community string 'public'. Many devices ship with these default settings, though it's certainly insecure for production environments.

You can use the snmpstatus command for this. Here’s an example of how you might do this in your terminal:

snmpstatus -v 2c -c public [IP-address_of_the_device]

Replace [IP-address_of_the_device] with the actual IP address or hostname of the device you wish to test.

What if You Get No Information Back?

If you don't receive any information after this attempt, don't panic. It simply means the default settings likely don't apply to your device, or there might be a network related issue. You'll need to dig deeper into your device's configuration or troubleshoot your network.

First, check the device's configuration:

SNMP Version: Which SNMP version (v1, v2c, or v3) is configured and enabled?
Community String (for v1/v2c): If your device uses SNMPv1 or SNMPv2c, what is the configured community string (similar to a password) for read-only and potentially read- write access? It's rarely 'public' in a properly configured environment.
Username, Authentication, and Privacy (for v3): If your device uses SNMPv3, you'll need more specific information:
Username: What username has been created for SNMPv3?
Authentication Protocol and Password: Which authentication protocol (e.g., MD5, SHA) is used, and what is its corresponding password?
Privacy Protocol and Password: Which encryption protocol (e.g., DES, AES) is used, and what is its corresponding password?

Next, consider potential network issues:

Even if your device is correctly configured, network obstacles can prevent SNMP communication. Check for:

Firewall Blocking: A firewall (either on your testing machine, the network, or the SNMP device itself) might be blocking the UDP port 161, which SNMP typically uses. Ensure the necessary ports are open.
ACL Settings on the Device: The SNMP device itself might have Access Control List (ACL) settings configured to restrict access only to specific IP addresses. Verify that your testing machine's IP address is permitted.
Network Connectivity: Basic network issues like incorrect IP addresses, subnet masks, or routing problems can also prevent communication. Ensure there's a clear network path between your testing machine and the SNMP device.

Examples of SNMPv3 Commands

Once you have the necessary information (and have ruled out network issues), you can try connecting with SNMPv3. Here are some examples of how you might use snmpstatus with SNMPv3 (depending on your configuration):

Authentication only (no encryption):

snmpstatus -v 3 -l authNoPriv -u [username] -a [authentication_protocol] -A [authentication_password]
[IP-address_of_the_device]

(Replace [authentication_protocol] with MD5 or SHA)

Authentication and Encryption:

snmpstatus -v 3 -l authPriv -u [username] -a [authentication_protocol] -A [authentication_password]
-x [privacy_protocol] -X [privacy_wachtwoord] [IP-address_of_the_device]

(Replace [authentication_protocol] with MD5 or SHA and [privacy_protocol] with DES or AES)

Next, consider potential network issues

Even if your device is correctly configured, network obstacles can prevent SNMP communication. Check for:

Firewall Blocking: A firewall (either on your testing machine, the network, or the SNMP device itself) might be blocking the UDP port 161, which SNMP typically uses. Ensure the necessary ports are open.

ACL Settings on the Device: The SNMP device itself might have Access Control List (ACL) settings configured to restrict access only to specific IP addresses. Verify that your testing machine's IP address is permitted.

Network Connectivity: Basic network issues like incorrect IP addresses, subnet masks, or routing problems can also prevent communication. Ensure there's a clear network path between your testing machine and the SNMP device.

A Note on SNMPv1: Avoid if Possible

While you can technically test with SNMPv1, we strongly advise against using it in production. SNMPv1 is an outdated and insecure protocol version vulnerable to various attacks. Always try to connect with v2c or v3 first. Only if you are absolutely certain that the device exclusively supports SNMPv1 and you have no other option, you can try using it:

snmpstatus -v 1 -c [community_string] [IP-address_of_the_device]

However, remember that using SNMPv1 in a production environment poses a significant security risk.

Understanding the Output of snmpstatus

Let's take a look at an example output from the snmpstatus command. Remember this is just an example output it will differ from your result.

snmpstatus -v2c -c public 127.0.0.1
[UDP: [127.0.0.1]:161->[0.0.0.0]:33310]=>[Linux localhost.localdomain 5.14.0-570.28.1.el9_6.aarch64
#1 SMP PREEMPT_DYNAMIC Thu Jul 24 07:50:10 EDT 2025 aarch64] Up: 1:24:36.58
Interfaces: 2, Recv/Trans packets: 355763/355129 | IP: 37414/35988

This output provides a concise summary of the device's status, indicating a successful SNMP query. Let's break down what each part means:

snmpstatus -v2c -c public 127.0.0.1:
-v2c: Specifies that SNMP version 2c was used.
-c public: Indicates that the community string "public" was used for authentication.
127.0.0.1: This is the target IP address, in this case, the localhost (the machine on which the command was run).
[UDP: [127.0.0.1]:161->[0.0.0.0]:33310]:
This section describes the communication path.
UDP: Confirms that the User Datagram Protocol was used, which is standard for SNMP.
[127.0.0.1]:161: This is the source of the SNMP request and the standard SNMP port (161) on which the SNMP agent listens.
->[0.0.0.0]:33310: This indicates the destination of the response. 0.0.0.0 is a placeholder for "any address," and 33310 is a high-numbered ephemeral port used by the client to receive the response.
=>[Linux localhost.localdomain 5.14.0-570.28.1.el9_6.aarch64 #1 SMP PREEMPT _DYNAMIC Thu Jul 24 07:50:10 EDT 2025 aarch64]:
This is crucial information about the queried device itself.
Linux localhost.localdomain: Identifies the operating system as Linux, with the hostname localhost.localdomain.
5.14.0-570.28.1.el9_6.aarch64: This is the kernel version and architecture
#1 SMP PREEMPT_DYNAMIC Thu Jul 24 07:50:10 EDT 2025 aarch64: Provides further kernel build details, including the build date and time.
Up: 1:24:36.58:
This indicates the uptime of the device. The system has been running for 1 day, 24 hours, 36 minutes, and 58 seconds.
Interfaces: 2, Recv/Trans packets: 355763/355129 | IP: 37414/35988:
Interfaces: 2: This tells us that the device has detected 2 network interfaces.
Recv/Trans packets: 355763/355129: These numbers represent the total number of packets received and transmitted across all network interfaces on the device since it was last booted.
IP: 37414/35988: These figures likely represent the number of IP datagrams received and sent specifically by the IP layer on the device. This provides a more specific metric of IP traffic compared to the total packet count which includes other layer 2 protocols.

In summary, this output from snmpstatus quickly provides a clear overview of a Linux system's basic health and network activity, confirming that the SNMP agent is reachable and responding with the requested information using SNMPv2c.

Installing SNMP Agent on a Linux Host

To install the SNMP agent and utilities on your Zabbix server or another compatible system, follow the steps below.

Install Required Packages

# Optional: Update the package list
sudo dnf update -y

# Install Net-SNMP agent and utilities
sudo dnf install -y net-snmp net-snmp-utils
2. Configure the SNMP Agent
First, create a clean configuration file for the SNMP daemon:

sudo vi /etc/snmp/snmpd.conf
# Or
sudo nano /etc/snmp/snmpd.conf

Paste the following example configuration, which is optimized for SNMP-based discovery and testing in Zabbix:

tee /etc/snmp/snmpd.conf <<EOF
# --------------------------------------------------------------------------
# BASIC ACCESS CONTROL
# --------------------------------------------------------------------------
# This defines who has access and with which community string.
# For a LAB ENVIRONMENT, 'public' is acceptable, but EMPHASIZE THAT THIS IS UNSAFE
# FOR PRODUCTION. In production, use SNMPv3 or restricted IP ranges.

# Read-only community string 'public' for all IP addresses (WARNING: LAB USE ONLY!)
rocommunity public
#
# IMPORTANT NOTE: The 'public' community string is the default and most well-known community string.
# Using this in a production environment is EXTREMELY INSECURE and makes your device vulnerable.
# Anyone who knows your device's IP address can query basic information about your system.
# USE THIS ONLY AND EXCLUSIVELY IN STRICTLY ISOLATED TEST OR LAB ENVIRONMENTS!
# For production environments:
# - Use a unique, complex community string (e.g., rocommunity YourSuperSecretString)
# - STRONGLY CONSIDER implementing SNMPv3 for superior security (authentication and encryption).
#

# BETTER FOR LAB (or production with restrictions):
# rocommunity my_secure_community_string 192.168.56.0/24
# Replace '192.168.56.0/24' with the subnet where your Zabbix Server is located.


# ============================================
# SNMPv3 Configuration (Recommended for Production, but here with examples)
# ============================================
#
# This section defines users for SNMPv3, each with a different security level.
# In a production environment, you would typically ONLY use the 'authPriv' option
# with strong, unique passwords. This setup is useful for lab and testing purposes.

# --- 1. SNMPv3 User with Authentication and Privacy (authPriv) ---
# THIS IS THE MOST SECURE AND RECOMMENDED SECURITY LEVEL FOR PRODUCTION.
# It requires both correct authentication and encryption of the traffic.
#
# Syntax: createUser USERNAME AUTH_PROTOCOL "AUTH_PASS" PRIV_PROTOCOL "PRIV_PASS"
# Example: createUser mysecureuser SHA "StrongAuthP@ss1" AES "SuperPrivP@ss2"

createUser secureuser SHA "AuthP@ssSec#1" AES "PrivP@ssSec#2"
rouser secureuser authPriv

# --- 2. SNMPv3 User with Authentication Only (authNoPriv) ---
# This level requires authentication, but the data is NOT encrypted.
# The content of SNMP packets can be read if traffic is intercepted.
# NOT RECOMMENDED FOR SENSITIVE DATA OR PRODUCTION ENVIRONMENTS.
#
# Syntax: createUser USERNAME AUTH_PROTOCOL "AUTH_PASS"
# Example: createUser authonlyuser SHA "AuthOnlyP@ss3"

createUser authonlyuser SHA "AuthOnlyP@ss3"
rouser authonlyuser authNoPriv

# --- 3. SNMPv3 User with [48;32;186;960;2604tNo Authentication and No Privacy (noAuthNoPriv) ---
# THIS IS THE LEAST SECURE LEVEL AND SHOULD NEVER BE USED IN PRODUCTION!
# It offers NO SECURITY WHATSOEVER. It's purely for very specific test scenarios
# where security is not a concern.
#
# Syntax: createUser USERNAME
# Example: createUser insecureuser

createUser insecureuser
rouser insecureuser noAuthNoPriv

#
# IMPORTANT SECURITY NOTES FOR ALL SNMPv3 USERS:
# - Replace the example usernames and passwords with your OWN strong, unique values.
# - Passwords must be a MINIMUM of 8 characters long.
# - The passwords for AUTH and PRIV (with authPriv) do not have to be the same.
# - Restrict access to specific IP addresses (e.g., 'rouser USERNAME authPriv 192.168.1.0/24')
#   if you want to further tighten access.
#


# --------------------------------------------------------------------------
# SYSTEM INFORMATION (OPTIONAL)
# --------------------------------------------------------------------------
# This information is generally available via SNMP and useful for identification.
syslocation  "Rocky Linux Zabbix SNMP Lab Server"
syscontact   "Your Name <your.email@example.com>"
sysname      "RockySNMPHost01" # Often overridden by hostname, but can be specific

# --------------------------------------------------------------------------
# ENABLING CRUCIAL MIB MODULES FOR LLD
# --------------------------------------------------------------------------
# 'view' statements determine which parts of the MIB tree are visible.
# 'systemview' is a standard view. We ensure that the most useful OID trees
# for Zabbix LLD are included here.

# Standard System MIBs (uptime, description, etc.)
view systemview included .1.3.6.1.2.1.1    # SNMPv2-MIB::sysDescr, sysUptime, etc.

# HOST-RESOURCES-MIB: ESSENTIAL FOR LLD OF HARDWARE/OS COMPONENTS
# This MIB contains information about storage (filesystems), processors,
# installed software, running processes, etc.
view systemview included .1.3.6.1.2.1.25

# IF-MIB: ESSENTIAL FOR LLD OF NETWORK INTERFACES
# Contains detailed information about network interfaces.
view systemview included .1.3.6.1.2.1.2

# Other useful MIBs (often standard or optional)
view systemview included .1.3.6.1.2.1.4
view systemview included .1.3.6.1.2.1.6
view systemview included .1.3.6.1.2.1.7

# --------------------------------------------------------------------------
# EXTENDING SNMPD WITH EXEC COMMANDS (OPTIONAL FOR CUSTOM LLD)
# --------------------------------------------------------------------------
# This allows you to make the output of shell commands or scripts available via SNMP.
# This is ideal for monitoring things not natively available via SNMP.
# Example: Monitor the number of logged-in users (not LLD, but demonstrates the principle)
# exec activeUsers /usr/bin/who | wc -l

# Example: A script that generates LLD-like output
# imagine /opt/scripts/docker_lld.sh returns JSON that Zabbix can parse
# exec dockerContainers /opt/scripts/docker_lld.sh
# This requires a custom LLD parser in Zabbix. For an introduction, this
# might be a bit too advanced, but it's good to mention as a possibility.

# --------------------------------------------------------------------------
# SYSLOGGING
# --------------------------------------------------------------------------
# For logging snmpd activities (useful for debugging)
dontLogTCPWrappers no
EOF

Let's do some practical tests with this setup we just created. Start the SNMP Service and Configure the Firewall

# Start the SNMP daemon
sudo systemctl start snmpd

# Enable it to start on boot
sudo systemctl enable snmpd

# Check that the service is running
sudo systemctl status snmpd
If your system uses firewalld, ensure that SNMP traffic is allowed:

# Add SNMP to permanent firewall rules
sudo firewall-cmd --add-service=snmp --permanent

# Reload the firewall configuration
sudo firewall-cmd --reload

# Confirm that SNMP is listed
sudo firewall-cmd --list-services --permanent

Verifying SNMP Functionality
From your Zabbix server or any SNMP client system with net-snmp-utils installed:

# Repace <IP_ADDRESS> wit the IP of the client where you installed the SNMP
# config. If localhost you can use 127.0.0.1.

# General system info (sysDescr, sysUptime, etc.)
snmpwalk -v2c -c public <IP_ADDRESS> .1.3.6.1.2.1.1

# List interface names (useful for interface LLD)
snmpwalk -v2c -c public <IP_ADDRESS> .1.3.6.1.2.1.2.2.1.2

# List filesystem descriptions
snmpwalk -v2c -c public <IP_ADDRESS> .1.3.6.1.2.1.25.2.3.1.3

# Get CPU load per processor core
snmpwalk -v2c -c public <IP_ADDRESS> .1.3.6.1.2.1.25.3.3.1.2

Note

For SNMPv3 we can do the same. You could adapt the configuration file or just go with what we have prepared already in the snmpd.conf file.

vi /etc/snmp/snmpd.conf

# Look for the following lines and adapt them as you like.

createUser authonlyuser SHA "AuthOnlyP@ss3"
rouser authonlyuser authNoPriv

createUser secureuser SHA "AuthP@ssSec#1" AES "PrivP@ssSec#2"
rouser secureuser authPriv

createUser insecureuser
rouser insecureuser noAuthNoPriv

After you have adapted your config don't forget to restart the snmpd service

systemctl restart snmpd

You should now be able to test your items with SNMPv3 Let me give you an example command for noAuthNoPriv,authNoPriv and the most secure authPriv. This should work out of the box with what is already configured in our snmpd.conf file.

snmpwalk -v3 -l noAuthNoPriv -u insecureuser 127.0.0.1 .1.3.6.1.2.1.2.2.1.2
snmpwalk -v3 -l authNoPriv -u authonlyuser -a SHA -A AuthOnlyP@ss3 127.0.0.1 .1.3.6.1.2.1.2.2.1.2
snmpwalk -v3 -l authPriv -u secureuser -a SHA -A AuthP@ssSec#1 -x AES -X PrivP@ssSec#2 127.0.0.1 .1.3.6.1.2.1.2.2.1.2

Note

If you change the config file and adapt the passwords and for some reason they do not get accepted do not worry just restart the service again it things still don't work you can remove the persistent key file sudo rm /var/lib/net-snmp/snmpd.conf It's quite brutal but in our test environment it will help you out.
